iStore Smart Battery 5000/15000 ES

Modular Battery Solutions

The iStore energy storage system is here. The perfect option to couple with any iStore inverter, the iStore Solar Battery can be modified to suit your energy needs, however large they may be.

Thanks to its modular design, rather than having to buy an additional battery if you want to expand your home's energy storage reserves, all you need to do is add another battery block to your iStore Solar Battery, saving you money and space. Due to this clever design, the iStore can scale in size anywhere from 5 kWh all the way to 30 kWh.

The iStore solar battery consists of stackable modules, each weighing 50kg, with a capacity of 5kWh. By connecting three modules together, you can create a 15kWh battery.

Furthermore, two sets of these 15kWh batteries can be connected in parallel to achieve a maximum capacity of 30kWh. Each battery stack can reach 5kW output power and 7kW surge power for 10s

  • Modular design allows for flexible investment
  • Perfect compatibility with both single and three phase iStore Hybrid inverters
  • More usable energy with 100% depth of discharge

Performance

Power Module
Number of modules
1
Rated charge and discharge power
5kW
Nominal voltage (single-phase system)
450V
Operating voltage (single-phase system)
350–560 V
Nominal voltage (three-phase system)
600V
Operating voltage (three-phase system)
600–980V



Communication
Display
SOC status indicator, LED indicator
Comms
RS485/CAN (only for parallel operation)



Models
IS-BATT-5000-BMS
IS-BATT-5000-ES



Battery Module
# Modules
1
2
3
Usable Energy
5kW
10kW
15kW
Max. output power
2.5kW
5kW
5kW
Peak output power
3.5 kW, 10s
7 kW, 10s
7 kW, 10s
